Our renowned MIMO Parabolic Antenna model of RFLINK ANTENNA is the RF-DP-D4964-30HV, characterized by a high front-to-back ratio and high gain (30 dBi).
Frequency Range(MHz):4900-6400 MHz
Gain:30 dBi
V.S.W.R:≤1.8
Center frequency characteristic impedance (Ω):50
Connector Type:SMA
| Frequency Range(MHz) | 4900-6400 MHz |
| Gain(dBi) | 30 |
| Horizontal Beamwidth(3dB) | 5.5° |
| Vertical Beamwidth(3dB) | 5.5° |
| Polarization | H+V |
| F/B Ratio | ≥ 32 dB |
| VSWR | ≤ 1.8 |
| Impedance | 50 Ω |
| Connector | 2 x N-Female |
| Max. Power | 100 W |
| Lightning Protection | DC Ground |
| Dimension | φ600mm |
| Weight | 5 kg |
| Operating Temperature | -40℃～+65℃ |
| Wind Loading | 180 km/h |
| Mounting | Pole Mount |
The RF-DP-D4964-30HV, our renowned MIMO Parabolic Antenna model from RFLINK ANTENNA, is designed for high-performance wireless communication. It features a high front-to-back ratio and high gain (30 dBi), making it ideal for 5G networks, wireless backhaul, and point-to-point communication systems.
Frequency Range (MHz): 4900-6400 MHz (Covers 5G bands for high-speed data transmission and long-range communication)
Gain: 30 dBi (High gain design ensures signal strength and coverage, perfect for long-distance wireless communication)
V.S.W.R: ≤1.8 (Low VSWR ensures good impedance matching and minimizes signal reflection)
Center Frequency Characteristic Impedance (Ω): 50 (Standard 50Ω impedance for compatibility with most wireless communication equipment)
Connector Type: SMA (Durable SMA connector provides reliable electrical and mechanical connection)
The RF-DP-D4964-30HV antenna features an advanced parabolic reflector design with a high-precision feed system for superior RF performance. Its compact and robust construction ensures stable operation in various harsh environments, making it an ideal choice for 5G base stations, wireless backhaul links, and high-performance wireless communication systems.
• Disaster recovery and rapid deployment of applications
• Campus and Academic Facilities
• High-power, long-distance point-to-point applications
• Municipal and Government Facilities
• Wireless Internet Providers and ISPs
• Security monitor
Dongguan RenFeng Electronic Technology Co.,Ltd
Email: bellasu@rflink.net.cn
Mobile Phone: +86 1379-4978-989
Address: No.1 Sankeng Qinghutou Tangxia Dongguan Guangdong China
FAQs for the 4900 - 6400 MHz 30 dBi MIMO Dish Antenna
1. What is the frequency range of this antenna?
The antenna operates in the 4900 - 6400 MHz range, making it suitable for 5G, WiMAX, and other wireless communication systems.
2. What is the gain of this antenna?
The antenna has a high gain of 30 dBi, ideal for long-distance, high-performance wireless links.
3. Is this antenna compatible with 5G networks?
Yes, the 4900 - 6400 MHz range falls within the 5G mid-band spectrum, making it perfect for 5G fixed wireless access (FWA) and backhaul applications.
4.What does MIMO mean, and why is it important?
MIMO (Multiple Input, Multiple Output) supports multiple data streams, improving signal reliability, speed, and capacity for high-bandwidth applications.
5. What are the typical applications of this antenna?
It is used for 5G networks, point-to-point links,WISP deployments, public safety communication, and ndustrial IoT connectivity.
