2.4 GHz 12 dBi Omni Fiberglass Antenna delivers high-gain, long-range performance for Wi-Fi, Bluetooth, and wireless systems. Its durable, weatherproof fiberglass design ensures reliable outdoor use, ideal for extending signal coverage.
Frequency Range(MHz)：433 MHz
Gain: 5 dbi
Center frequency characteristic impedance (Ω)：50
Connector Type：N-Female or N-Male
| Frequency Range(MHz) | 2400-2500 MHz |
| Gain(dBi) | 12 dBi |
Horizontal Beamwidth(3dB) | 360° |
Vertical Beamwidth(°) | 6° |
Polarization | Vertical |
| VSWR | ≤ 1.5 |
Impedance | 50 Ω |
| Connector | N-Female or Customized |
| Max. Power | 100 W |
| Lightning Protection | DC Ground |
Dimension | Φ20 x 1250 mm |
Weight | 0.46 kg |
Operating Temperature | -40℃～+65℃ |
Wind Loading | 214km/h |
Mounting | Pole Mount |
Our new kind of antenna with a protective UV-inhibiting covering is the fiberglass omni antenna, which is encased in high density fiberglass. The omni antenna made of fiberglass is specifically made for outdoor use. In situations where outside connectivity is necessary, such as wireless communication networks, point-to-multipoint connections, and cellular network architecture, the fiberglass omni antenna is frequently utilized.
With a frequency range of 2400 MHz to 2500 MHz, the fiberglass omni antenna is precisely calibrated to guarantee that your signal reaches its target regardless of the application.
The fiberglass omni antenna has a precise beamwidth and extensive coverage. Your signal will be precisely focused where you need it thanks to the horizontal beamwidth of less than 1.5 degrees, which maximizes coverage while reducing interference.
As you know, the fiberglass omni antenna is a antenna, therefore it has a good perfromance in the weather resistance. It can function effectively at temperatures between -40°C and +65°C. Throughout the year, this antenna can withstand extremely high or low temperatures and maintain constant contact.
This fiberglass omni antenna is also wind-resistant and lightweight. It weighs approximately 0.46 kg, making it easy to handle and install. You can depend on its steadiness in inclement weather because it is made to resist winds of up to 214 km/h.
Lightning protection is another feature of the fiberglass omni antenna. Your network equipment is protected from erratic weather conditions with DC Ground lightning protection, protecting your investments.
• Bluetooth® & Public Wireless Hotspot
• 2.4 GHz Indoor/Outdoor Wireless LAN systems
• Supports IEEE 802.11b/g/n applications
• WiFi and 2.4 GHz wireless video systems
• Public safety
Dongguan RenFeng Electronic Technology Co.,Ltd
Email: bellasu@rflink.net.cn
Mobile Phone: +86 1379-4978-989
Address: No.1 Sankeng Qinghutou Tangxia Dongguan Guangdong China
FAQ for 2.4 GHz 12 dBi Omni Fiberglass Antenna
1. What is the antenna’s frequency range, and where is it used?
This antenna operates in the 2.4 GHz frequency range, making it perfect for Wi-Fi, Bluetooth, and other wireless communication systems that require high-performance signal transmission.
2. What does the 12 dBi gain mean for performance?
The 12 dBi gain significantly boosts signal strength and range compared to standard antennas, ensuring better coverage and reliability for both indoor and outdoor applications.
3. Is the antenna suitable for outdoor use?
Yes, the fiberglass construction is rugged and weatherproof, making it ideal for outdoor installations where durability and resistance to environmental factors are essential.
